Spring-loaded pressure regulator
Material: 316L
Max. pressure: 1,000 bar | Range: 0 – 700 bar
Temp range: -45°C / +150°C | Flow: 2.8 Nm³/h
Dome-loaded pressure regulator
Material: 316L
Max. pressure: 350 bar | Range: 5 – 220 bar
Temp range: -45°C / +150°C | Flow : 48 Nm³/h
Proportional valve
Material: Brass
Max. pressure: 100 bar | Range: 0 – 100 bar
Temp range: -45°C – +150°C | Flow: 2.8 Nm³/h
Spring back pressure regulator
Material: 316L
Max. pressure: 550 bar | ▪ Range: 1,5 – 500 bar
Temp range: -45°C / +150°C | Flow: 1.8 Nm³/h
Safety valve – High pressure
Material: 316L
Pressure Range: 8 – 1100 bar
Temp range: -40°C – +99°C | Flow: > 5,000 Nm³/h
Thermal Pressure Relief Device
Material: 316L / Aluminum
Max. pressure: 1015 bar | Seat size: 2.4mm – 7 mm
Set point: 129°C ± 3°C | Trigger time: <2 min (@600°C)
Flow capacity: 547 kg/h (152g/s) @ 875 bar
Compliance: ISO 15500-13, TPED optional
1000 bar Multiplicator piloted pressure reducer
Developed to ISO 19880-3 specifically for Hydrogen gas
MWP : 1050 bar | Setting P : 100 to 950 bar
Seat size : 4 mm / Cv=0,46 | Piloting P : 0 to 7 bar
T° range : -40°C to +85°C
1000 bar hydrogen filter
Developed specifically for Hydrogen gas
5 µm Stainless steel clothed cartridge
MWP : 1100 bar | Internal orifice 9,2 mm
T° range : -40°C to +99°C
Energized PTFE omniseal seals
Pressure reducer line (No overshoot)
Developed specifically for Hydrogen gas
25 µm stainless steel clothed filter
MWP : 400 bar | Setting P : 0 to 250 bar
Seat size : 6 mm / Cv = 1 | T°range : -40°C to +99°C
No overshoot, No Precharge
Cryogenic safety valve
Developed specifically for Liquid Hydrogen
MWP : 100 bar | Setting P : 5 to 10 bar
Inlet port : 2″ BSPP | Outlet port : 3″ BSPP
T° range = -253°C to -246°C | PED 2014.68.UE Cat IV
1000 bar Cryogenic filter
Developed specifically for Liquid Hydrogen
MWP : 1100 bar | 5 µm Stainless steel clothed cartridge
Internal orifice 9,2 mm | High flow model available
T° range = -253°C to +45°C | In line or T-shape
Dynamic proportional valve
Developed specifically for Hydrogen and Oxygen gas
MWP : 50 bar | Setting P : 0 to 30 bar
Seat size : 12 mm / Cv = 4 | Q = 3900 Nl.min-1 at 21 bar
Dynamic regulation | T° range : -40°C to +85°C
V635 type Slam shut valve
Developed specifically for Hydrogen gas
MWP : 450 bar | Setting P = 10 to 350 bar
Seat size : 10 mm | T° range : -40°C to +99°C
Self sufficient Safety valve | PED 2014.68.UE Cat IV
High temperature check valve
Developed specifically for Hydrogen gas
MWP : 700 bar | Internal orifice : 6 mm
T° range : -40°C to 200°C
